Technical Details

• High power-to-weight ratio (5 amp motor; 3.5 lbs.)
• Ergonomically designed for reduced operator fatigue
• Large trigger switch for easy operation
• Conveniently located reversing switch
• Idling mechanism prevents hammering while idling

• High power-to-weight ratio (5 amp motor; 3.5 lbs.)
• Ergonomically designed for reduced operator fatigue
• Large trigger switch for easy operation
• Conveniently located reversing switch
• Recessed lock-on button
• Idling mechanism prevents hammering while idling
• Side handle swivels 360° for convenient operation

What's in the Box

• Drill chuck (763114-3)
• Chuck key (763430-3)
• Depth gauge (415486-9)

SPECIFICATIONS

• Capacities: Concrete 9/16"; Steel 1/2"; Wood 1"
• No load speed: 0 - 2,800 rpm
• Blows per minute: 0 - 44,800
• Amps: (115V) 5.0
• Overall length: 11-3/8"
• Net weight: 3.5 lbs.
• Shipping weight: 5.1 lbs.
