Product Information

FEATURES

• 15 Amps, 3,900 RPM
• Superior motor insulation  Extra motor over-load protection during tough applications
• Locking vise with quick release  Holds awkward material stable for fast and efficient cutting
• Adjustable fence  Adjusts for bevel cuts ranging from 0-45°
• Trigger w/lock-on  For extended use applications
• Spindle lock  For quick wheel changes
• Ball and roller bearing construction  Smooth power transmission and extended tool life
• Adjustable depth stop  Takes the guesswork out of cutting specific depths
• Precision helical steel gears  Quality engineering and construction ensures longer life
• Built-in wheel wrench storage  Stows in base for easy access
• Hold down chain  Secures the tool for easy transport
• Large carrying handle
• Double Insulated, UL listed, complies to OSHA

Includes:

• Wrench -- included
• 36 Grit Aluminum Wheel -- BB1400

SPECIFICATION

Model Number	3814
Amperage	15.0
No Load RPM	3,900
Arbor Size	1″
Length	5/8″
Weight (lbs.)	42
Engineering Number	0601471039
Rating	120V AC
Wheel Diameter	14″
Cutting Capacity-Square Stock	4″
Max. Capacity Sq. Stock	4″
Max. Motor HP	4.0
Max Capacity Pipe O.D.	5″
Cutting Capacity-Pipe	5″ (o.d)
Spindle Thread	5/8″-11
Depth of Cut	6″
