Technical Details

• Heavy gauge aluminum wraparound base ensures stable support
• Shaft lock for easy blade replacement
• Heavy duty 13 amp motor for continuous operation
• Ball bearing construction
• AC/DC switch for use with alternative power sources

• 13 AMP motor for continuous use
• Heavy gauge aluminium wraparound base
• Well balanced design Shaft lock for fast blade changes
• Ball and needle bearing construction
• Includes thin kerf carbide tipped blade
• AC/DC
• Includes: Carbide tipped blade (a-90009, 16 teeth)
• Wrench #13 (781203-2)
• Plastic tool case (824409-0)
• Specifications: Blade diameter: 7-1/4" (185mm) Arbor: 5/8" (15.88mm) Max cutting capacities: at 90 degrees 2-3/8" (60mm), at 45 degrees 1-3/4" (46mm) No load speed: 5,800 RPM AMPS (115V): 13.0 Overall length: 11-5/8" (295mm) Net weight: 11.0 lbs. (5.0 kg) Shipping weight: 18.3 lbs. (8.2 kg)
